PARAMETERISATION SOFTWARE PASO

With the PASO software, all configuration and parameterisation can be carried out via

the intuitive user interface with a laptop. In addition, as all important signals can be re-
corded or analysed on the screen in real time, the software also provides the possibility
of troubleshooting.

FUNCTIONALITIES
Despite the multitude of application possibilities, PASO is very
user-friendly and easy to operate. The functional process is
displayed on the screen as a block diagram. By clicking on
one of the block diagram symbols, a menu window opens in
which the parameters associated with the process can be set.
In addition to the connecting lines between the blocks, the
feedback value being passed onto the following block is also
displayed in real time. In this way, it is possible to monitor the
effects of a parameter change on the entire system on the
computer, allowing fine tuning to be performed quickly and

precisely. The set values can then be saved in a parameter file

and can also be loaded directly into a new electronic module.

PARAMETERISATION AND PROGRAMMING ADDITIONAL EXECUTIONS
• PC software PASO (freely available) • Customer-specific software expansions

• Individual process data monitoring • Hardware expansion for additional functions
• Integrated oscilloscope • Software for application-optimised solutions

• Remote control functions • Flexible interface definition
• Fieldbus Interface • Electronics integrated in the valve
