VALVE ELECTRONICS DSV
MINIATURE AMPLIFIER PD2, PD3
COMMUNICATION MODULES CL-T
CAN INTERFACE
WANDFLUH MOBILE | PRODUCTS
CHARACTERISTICS
Digital amplifier electronics DSV (Digital Smart Valve) directly
integrated in the valve for controlling a proportional valve.
FEATURES
• Type amplifier or controller
• Controller modes selectable: pressure, position, speed
• Valve factory set
• Control via solenoid current with dither signal
• Command values as voltage or current
• 2 digital inputs and 1 output
• Parameterisable by means of PASO software
• Optional with fieldbus (CANopen, Profibus DP)
• Protection class IP67
CHARACTERISTICS
Digital amplifier module for controlling a proportional valve.
PD2 is an electronics unit with cable connection. In the MPS
version, it is mounted fixed on a solenoid.
FEATURES
• IP67 housing
• Solenoid current regulated
• Command value as voltage or current
• Digital input
• Parameterisable by means of PASO software or display
and buttons on the device
• Optional with fieldbus (CANopen or J1939)
• Housing with cable connections or mounted on the solenoid
CHARACTERISTICS
The module allows wireless data transmission over various
communication channels.
FEATURES
• Remote diagnosis of the machine
• Tracking
• Remote control of machine functions
• Data recording of any signal
• Functions programmable
• GPS receiver for position recognition
• Communication via GSM and WiFi
• Robust housing with IP67 protection
CHARACTERISTICS
Simple communication interface for electronics controls in
the mobile industry.
FEATURES
• Protocol for bidirectional data transmission
• Protocols: CANopen or J1939
• Allows status and diagnosis queries of the device
• Parameterisation via CAN
• Electronic Device Description (EDD) available
| TYPICAL ELECTRONICS | PAGE 11
