TYPICAL ELECTRONICS

For the control of proportional valves, electronic control devices are required. They
control the solenoid current on the valve and thus ensure a very sensitive actuation of
the valve. Control devices are available in a wide range of executions, in order to fulfil the
requirements of different tasks in varied fields of application.

AMPLIFIER / CONTROLLER CONTROLS MD2 CHARACTERISTICS
Digital amplifier and controller module for use in harsh envi-

ronments. With the device, there are up to 8 solenoid outputs
available for control tasks of all types.
FEATURES
• Robust and compact construction with protection class
IP67
• Solenoid outputs can be used as proportional output or
switching solenoid output
• Command values in the form of voltage, current,
frequency, PWM
• Up to 4 analogue and 4 digital inputs
• Up to 10 digital outputs
• Optional with CANopen fieldbus

• Screw fixing of the housing

PROGRAMMABLE CONTROLS CL-7 CHARACTERISTICS
Micro-controller-based control with display and operating
buttons including multifunctional inputs/outputs.

FEATURES
• Functions freely programmable
• Display graphics freely configurable

• Video signal input
• High resolution display
• Monitor sizes 4,3" and 7"
• Robust housing with IP67 protection

KEYBOARDS CL-6 CHARACTERISTICS
Intelligent keypad for interaction with the machine operator.
With integrated display and controller functions.
FEATURES
• Wear-free buttons with LED displays
• Digital inputs and outputs
• Direct control of valves
• Functions freely programmable
• Robust housing with IP67 protection
• Optional customer-specific key labelling
