INDIVIDUAL SOLUTIONS

Wandfluh valves are modular in structure and can therefore be put together very flexibly.
This allows different standard functional components to be combined with one another to
easily create individual solutions.

SOFT SWITCHING VALVES CHARACTERISTICS
When switching a direction of travel or rotation, switching
shocks place a heavy load on the mechanics and cause un-

pleasant impulses. The valve can softly switch high flows
and thus protects the machine and the operator.
FEATURES
• 3-way execution
• Cartridge execution
• Remotely controlled via a pressure signal
ACB-S AC1-S CB2-S
A
B
A B • Pressure max. 350 bar A B
• Flow max. 200 l/min
• Nominal size M33 Y X Y
X P T Y X P T P T

SPOOL VALVES SOLENOID AND MECHANICALLY ACTU- CHARACTERISTICS
ATED The valve can be remotely controlled by appropriate electron-
ics or manually operated on site.

FEATURES
• Completes the electrical actuation with a hand lever actua-
tion for 3-way valves
• For switching and proportional valves
• In combination with standard and Ex d / Ex i solenoids

A B
a 0 b
a b
P T

SPOOL VALVES 6/2-WAYS CHARACTERISTICS
Spool valve for alternative control of two consumers.

FEATURES
• 2-way execution with 6 connections
• Option with soft switching
• Pressure max. 315 bar
• Flow max. 50 l/min
• Pipe thread connections
