Solenoid accessory

Screw plug with or without
integrated manual override

DESCRIPTION FUNCTION APPLICATION
The screw plugs are screwed into sole- When commissioning a machine or in case The screw plug HB0 allows air bleeding ac-
noids or armature tubes with a M8 x 0,75 of a power supply failure, the function of the cording to data sheets 1.4 and 1.11.
thread. Two different types are available: a nor- solenoid can be replaced by means of the To ensure a correct functionning, the screw
mal screw plug made of zinc coated steel and manual override. plugs with integrated manual override HB4,5,
a screw plug with integrated manual override HB6 and HB8,5 must be screwed into the
made of stainless steel. solenoids contained on the type list only.

TyPE LIST
Type/Article no. Solenoid types
Scew plug Can be used for all standard - solenoid types
HB0
Article no. 239.2033
Screw plugs with
integrated manual override
HB 4,5 SIN29V / SIS29V / PI29V / BSIIIV
Article no. 253.8000 SIN35V / SIS35V / PI35V / BEIIV
HC 4,5 10 SMS16/50S (SDSPM18)
4 Article no. 253.8017
6
HB 6 SIN45V / SISV45 / PI45V
Article no. 253.8001
HB 8,5 SIN60V / SIS60V / PI60V
Article no. 253.8002
HC 8,5 PMS31/72S (QN/QDPPM42)
Ø 11 Article no. 253.8022 M8x0,75
s4
DIMENSIONS
Screw plug HB0 Screw plug with integrated manual override

L1
10 L2 6 L3 L4
4 6
L1 L2 L3 L4
HB 4,5 9 3 3,2 5
HB 6 10,5 4,5 3,7 6,5
9
HB 8,5 13
7
4,2
20
9,7
Ø 11 M8x0,75 Ø 5 M8x0,75 HC 4,5 9 3 12,7 5
HC 8,5 13
9
7
s4
L1 s13 30
L2 6 L3 L4
PARTS LIST
Position Article Description
20 160.6076 O-ring ID 7,65 x 1,78 (FKM)
20 160.6026 O-ring ID 2,60 x 1,20 (FKM)
30
Ø 5 M8x0,75

Wandfluh AG Tel. +41 33 672 72 72 E-mail: sales@wandfluh.com Illustrations not obligatory Data sheet no.
Postfach Fax +41 33 672 72 12 Internet: www.wandfluh.com Data subject to change 1.1-300E 1/1
CH-3714 Frutigen Edition 15 35
